Product Details
Product Introduction
Travel Lightweight Strip Washing Liquid Bath Liquid Multi-Lane Automatic Weight Checker can accommodate almost any precise weighing of small-package products for high-speed assembly line production applications. ta can provide up to 12 independent channels, saving space. Each lane works independently without interfering with each other, and independently detects the weight of each product. If you are interested in Multi-Lane Automatic Weight Checker, please feel free to contact us.Welcome to consult for quotation information!
Technical Parameters
Weighing Range:1-30g
Minimum Scale:0.01g
Sorting Speed:Maximum 50 pieces/min (one channel)
Conveying Speed:20-100m/min
Operation Method:Touch operation
Conveying Direction:Can be placed according to the actual situation on site
Elimination Method:Lifting Rejection
Belt Height From The Ground:450±50mm (can be customized according to customer requirements)
Machine Structure:Stainless steel (SUS304)
Power Supply:220V 50-60HZ
Power:About 300W
Windshield:Thick acrylic (to avoid airflow interference)
Working Environment:Temperature: 0℃～40℃, Humidity: 30%～95%
Main Features
1. Large screen display, clear viewing and convenient operation.
2. The default Chinese and English operation interface (multiple languages can be customized).
3. Weight compensation function.
4. Histograms and graphs are used for customers to analyze product qualification rate.
5. Three-level operation authority management, support self-set password.
6. Can store 100 and product formula presets.
7. Multiple ways to remove unqualified products.
8. Multi-channel pass the product to improve production efficiency (the number of channels can be customized).
Application
Our Exhibitions
Package & Shipping
1.Before packaged, the machines will be tested strictly to guarantee the stability and high accuracy.
2.After tested, the machines will be wrapped with plastic sheet and carefully packed in wooden cases.
Packing Detail:
1.Each Machine with plastic film package first, then placed in a wooden case, wooden case with a foam filling.
2.We loaded the truck with heavy trucks for loading the cargo to the harbor terminal.At the dock we pack the goods in containers and ship them abroad.
After Sale Service
1.Product quality commitment
(1).There are quality records and testing data for the manufacture and testing of products.
(2).For the inspection of product performance,we sincerely invite users to inspect the whole process and performance of the product in person.After the product is confirmed to be qualified,it will be packaged and shipped.
2.the product price commitment
Under the same competitive conditions, our company will sincerely provide you with a preferential price on the basis of not reducing the technical performance of the product or changing the product components.
3. Delivery time commitment
Product delivery time: as far as possible according to user requirements,if there are special requirements, it needs to be completed in advance,and strive to meet user needs.
