If you are interested in Precise Dynamic Multi-lane Checkweigher Individual Stick Pack,please contact me! WhatsApp:+86 18302121916
E-mail: qin@checkweigher-sg.com
Product Details
Product Introduction
Precise Dynamic Multi-lane Checkweigher can be connected to the outlet of a multi-row packaging machine to check the weight of long soft packages in each row and remove underweight or overweight products to the unqualified area.Multi-lane Checkweigher Individual Stick Pack can detect the weight of multiple rows at the same time, greatly increasing the weighing speed and avoiding empty bags, underweight and overweight bags.
Technical Parameters
Type:SG-10XM
Weighing scope: 2-300g
Restrictions of product:L:180 W:40 H:2-20(mm)
Accuracy:±0.01g (Depends on products)
Division scale:0.01g
Belt width:30mm
Highest speed:70pcs/min(one lane)
Weight of machine:about 200Kg
Powder supply：AC220V 50HZ
Power:about 300W
Main material:SUS304(Stainless Steel)
Multi-channel passing products to improve production efficiency (the number of channels can be customized)
Main Features
1. It is suitable for multi-row simultaneous automatic weight detection of small packaging products such as food, medicine, and daily necessities
2. Greatly improved the detection speed per unit time
3. Effectively prevent empty bags, underweight, overweight and other defective products
4. Count the passed products, and automatically remove unqualified products by the sorting device
5. It can be matched with multi-column packaging machines, automatic filling machines, metal detectors, etc.
6. Customized according to the requirements of the on-site production line, and can be configured with automatic barcode scanning and inkjet system
7. The number of detection columns can be customized according to customer needs (such as double columns, four columns, six columns, ten columns, etc.)
8. Each channel can eliminate unqualified products separately.
9. The number of consecutive unqualified products in each channel can be modified.
10. Statistical data of each channel: real-time result display, trend graph display, and histogram display.
Application
Our Company
Our Customers
Our Exhibitions
Package & Shipping
1.Before packaged, the machines will be tested strictly to guarantee the stability and high accuracy.
2.After tested, the machines will be wrapped with plastic sheet and carefully packed in wooden cases.
Packing Detail:
1.Each Machine with plastic film package first, then placed in a wooden case, wooden case with a foam filling.
2.We loaded the truck with heavy trucks for loading the cargo to the harbor terminal.At the dock we pack the goods in containers and ship them abroad.
